Mini Pivot
Center Pivots
The compact solution for small-scale irrigation. Designed for small fields, specialty crops, and limited water resources, the Mini-Pivot delivers efficient irrigation with Reinke’s trusted durability.
Learn More
Resources
Guides and insights designed to help you maximize efficiency, improve productivity, and make the most of your irrigation systems.
view all resources
product breakdown
Specifications
PERFORMANCE FEATURES
System Series
Mini Pivot
Max System Length
1,300’
Pipe Diameters
4 ½”
Pipe Materials
High-Strength Steel
Pipe Coatings
TKTK
Span Connection
Hook & Receiver
Span Outlet Spacing
57”, 114”
Span Percent Slope
Up to 14%
Wheel Gears
Up to 14%
Tires
11” x 22.5”, 11.2” x 24”, 320/85R24, 14.9” x 24”, 16.9” x 24”

SUMMARY OF NEW SYSTEM LIMITED WARRANTY
WARRANTY
Reinke Irrigation Systems have a standard two (2) year limited warranty and extended warranties on certain primary components as listed below:
Water Pipe
Reinke 10/16
Or 16,000 hours of operation, whichever shall occur first.
25 Years
Span Joint Water Hose (Boots)
10 Years
Structural failure due to corrosion
- Galvanized Steel
- CN+
- Aluminum
- Stainless Steel
- Poly-Lined
20 Years
Drive Train
Reinke 10/16
Or 16,000 hours of operation, whichever shall occur first.
10 Years
Standard Duty
Or 10,000 hours of operation, whichever shall occur first.
10 Years
Moderate Duty
Or 6,000 hours of operation, whichever shall occur first.
5 Years
Structural Components
Manufactured directly by Reinke Manufacturing Co., Inc.
5 Years
Precision Technology
Reinke 10/16
5 Years
RPM Advanced Plus™ Panel
5 Years
RPM Touch Screen Panel
5 Years
RPM Connect™ Panel
5 Years
Navigator™ EOS GPS
2 Years
RC3™
3 Years
